Historical Context and Origins

The Brydon Cast Rendered house, also known as the No-Fines house, is a distinctive property type that emerged in the 1940s. Designed and manufactured by W H Webb, these houses were part of the post-war effort to address the acute housing shortage in the UK. The term “No-Fines” refers to the type of concrete used in their construction, which lacks fine aggregates, resulting in a more porous and lightweight material. This innovative approach allowed for quicker and more cost-effective construction, making it a popular choice during that era.

Typical Locations and Distribution

Brydon Cast Rendered houses are predominantly found in suburban areas across the UK. They were built in significant numbers, particularly in regions that experienced extensive bomb damage during World War II. These properties are often located in estates developed by local authorities and housing associations, reflecting the social housing policies of the time.

Architectural Characteristics

External Features

Brydon Cast Rendered houses are easily identifiable by their 2-storey detached structure and steep pitch gable roofs covered with plain tiles. The external walls are rendered throughout, providing a uniform and somewhat austere appearance. A notable feature is the front porch with a pitched tiled roof, adding a touch of character to the otherwise functional design. Metal casement windows with externally tiled sills are another distinctive element, contributing to the overall aesthetic.

Internal Layout

Internally, these houses typically feature a ground floor with timber block flooring or quarries on screed on concrete. The first floor comprises tongue-and-groove (T&G) boarding on timber joists housed in pockets cored into the external walls. Insulation mats are laid over the joists, providing some degree of thermal efficiency. The partitions on the ground floor are made of 4″ clinker concrete, while the first floor partitions are 2 1/2″ clinker concrete.

Construction Details

Substructure

The substructure of Brydon Cast Rendered houses consists of concrete underbuilding and a concrete slab thickened below loadbearing walls. A damp-proof course (DPC) is incorporated to prevent moisture ingress from the ground.

External Walls

The external walls are constructed using 8″ clinker no-fines reinforced concrete (RC) with 3/8″ bars below window openings, 1/2″ bars at the first floor level, and eaves level encased in dense concrete over openings. A lead sheet damp-proof membrane (DPM) is placed over openings to further enhance moisture resistance. A brick course and timber wall plate complete the wall structure.

Roof

The roof is supported by timber trusses and purlins, covered with plain tiles. This traditional roofing method provides durability and a classic appearance.

Variants

Some variants of the Brydon Cast Rendered house feature a substructure of reinforced concrete (RC) footings and concrete underbuilding. The external walls in these variants are made of 10 1/2″ no-fines clinker concrete. The first floor may have timber joists located in hollow breeze blocks cast into the external walls, offering slight variations in structural integrity and thermal performance.

Typical Hazards and Risks

Structural Issues

One of the primary concerns with Brydon Cast Rendered houses is the potential for structural issues due to the use of no-fines concrete. This material, while innovative, can be prone to cracking and spalling over time, particularly if not properly maintained. The reinforcement bars within the concrete can corrode, leading to further deterioration and potential structural instability.

Moisture Ingress

Despite the inclusion of DPC and DPM, moisture ingress can still be a problem, especially if the membranes have been compromised or if there are issues with the external rendering. Persistent dampness can lead to mould growth and deterioration of internal finishes, posing health risks to occupants.

Thermal Efficiency

The thermal efficiency of Brydon Cast Rendered houses is generally lower compared to modern standards. The no-fines concrete, while providing some insulation, does not offer the same level of thermal performance as contemporary materials. This can result in higher heating costs and a less comfortable living environment.

Asbestos

As with many properties built in the mid-20th century, there is a risk of asbestos being present in Brydon Cast Rendered houses. Asbestos was commonly used in various building materials, including insulation, ceiling tiles, and roofing felt. It is crucial to identify and manage any asbestos-containing materials to prevent health hazards.

Defective Premises Act Considerations

Brydon Cast Rendered houses are not specifically classified as defective under the Defective Premises Act. However, given their age and the potential for structural and maintenance issues, it is essential for buyers and investors to conduct thorough surveys and assessments. Identifying and addressing any defects early on can prevent costly repairs and ensure the property remains safe and habitable.

Inspection and Assessment Guide

External Inspection

1. Roof: Check for missing or damaged tiles, and inspect the condition of the timber trusses and purlins. Look for signs of sagging or unevenness, which could indicate structural issues.
2. Walls: Examine the rendering for cracks, spalling, or areas of dampness. Pay particular attention to the areas around window openings and the base of the walls where moisture ingress is more likely.
3. Windows and Doors: Inspect the metal casement windows for signs of rust or deterioration. Ensure that the external tiled sills are intact and properly sealed.
4. Porch: Check the condition of the front porch, including the pitched tiled roof and supporting structure.

Internal Inspection

1. Ground Floor: Assess the condition of the timber block flooring or quarries on screed. Look for signs of dampness or unevenness, which could indicate issues with the concrete slab or DPC.
2. First Floor: Inspect the T&G boarding and timber joists for signs of wear or damage. Ensure that the insulation mats are in place and in good condition.
3. Partitions: Check the clinker concrete partitions for cracks or other signs of structural issues.
4. Ceilings: While the specific ceiling construction is not known, it is important to look for signs of sagging, staining, or other indicators of potential problems.

Structural Assessment

1. Reinforcement Bars: Use non-destructive testing methods to assess the condition of the reinforcement bars within the no-fines concrete. Look for signs of corrosion or other deterioration.
2. Concrete Quality: Evaluate the overall quality of the no-fines concrete, checking for areas of weakness or significant cracking.
3. Moisture Levels: Use moisture meters to assess the levels of dampness in the walls and floors. Identify any areas where the DPC or DPM may have failed.

Common Defects and Maintenance Tips

Cracking and Spalling

Regularly inspect the external rendering for cracks and spalling. Address any issues promptly to prevent further deterioration. Consider applying a protective coating to enhance the durability of the rendering.

Moisture Management

Ensure that the DPC and DPM are intact and functioning correctly. Address any signs of dampness immediately, and consider installing additional moisture barriers if necessary. Proper ventilation is also crucial to prevent condensation and mould growth.

Thermal Upgrades

To improve the thermal efficiency of Brydon Cast Rendered houses, consider upgrading the insulation in the walls, roof, and floors. Double-glazing the metal casement windows can also enhance thermal performance and reduce heating costs.

Asbestos Management

If asbestos-containing materials are identified, it is essential to manage them safely. Engage a professional asbestos surveyor to assess the extent of the issue and recommend appropriate remediation measures. Do not attempt to remove or disturb asbestos materials without professional assistance.

Conclusion

The Brydon Cast Rendered house represents a unique chapter in the history of UK housing. While these properties offer a distinctive architectural style and historical significance, they also come with specific challenges and risks. For home buyers and investors, understanding these aspects is crucial to making informed decisions and ensuring the long-term viability of the property.
