Overview of the Gregory House

The Gregory House, a distinctive property type in the UK, has a rich history and unique construction characteristics that make it a subject of interest for home buyers and investors alike. Built from 1954 onwards, these properties were manufactured by Gregory Housing Ltd and Drury & Co. Ltd, with a total of approximately 1,500 units constructed. Known for their 2-storey semi-detached design, Gregory Houses are easily identifiable by their mansard hipped roofs covered with concrete tiles and external walls made of reconstituted stone-faced clinker PC blocks.

Historical Context and Manufacturers

Period of Construction

The Gregory House emerged in the post-war era, a time when the UK faced a significant housing shortage. The period from 1954 onwards saw a surge in the construction of system-built properties, designed to be both cost-effective and quick to assemble. Gregory Housing Ltd and Drury & Co. Ltd were at the forefront of this movement, contributing to the rapid expansion of housing stock during this period.

Manufacturers and Designers

Gregory Housing Ltd and Drury & Co. Ltd were the primary manufacturers of Gregory Houses. These companies were known for their innovative use of prefabricated reinforced concrete (PRC) in residential construction. The design of these houses was a collaborative effort, incorporating the expertise of architects and engineers to create a durable and functional living space.

Typical Characteristics of Gregory Houses

Structural Features

Gregory Houses are characterized by their 2-storey semi-detached layout, making them a popular choice for families. The mansard hipped roof, covered with concrete tiles, provides a distinctive aesthetic while also offering practical benefits such as improved drainage and additional living space in the attic.

External Walls

The external walls of Gregory Houses are constructed from reconstituted stone-faced clinker PC blocks up to the first-floor level, with tile hanging on the mansard above. This combination of materials not only enhances the visual appeal of the property but also contributes to its structural integrity.

Internal Layout

Internally, Gregory Houses typically feature a concrete ground floor and timber joists with tongue-and-groove boarding on the first floor. The separating walls are made of lightweight PC block cavity walls, providing adequate sound insulation between adjoining properties.

Typical Hazards and Risks

Spalling of External Walls

One of the most common issues with Gregory Houses is the spalling of external wall clinker PC blocks. This occurs when moisture penetrates the surface of the blocks, causing them to crack and flake. Over time, this can compromise the structural integrity of the walls and lead to costly repairs.

Inadequate Cover to Reinforcement in PRC Columns

Another significant risk associated with Gregory Houses is the inadequate cover to reinforcement in PRC columns. This can result in the corrosion of the steel reinforcement, weakening the columns and potentially leading to structural failure.

Medium Chloride Level in PRC Columns

The presence of medium chloride levels in PRC columns is also a concern. Chlorides can accelerate the corrosion of steel reinforcement, further exacerbating the risk of structural damage.

Defective Premises Act and Gregory Houses

Designated Defective

Under the Defective Premises Act, Gregory Houses are designated as defective due to the aforementioned issues with spalling, inadequate cover to reinforcement, and chloride levels in PRC columns. This designation means that owners of these properties may be eligible for financial assistance to carry out necessary repairs and improvements.

Inspecting a Gregory House: A Step-by-Step Guide

Pre-Inspection Preparation

Before conducting an inspection of a Gregory House, it is essential to gather all relevant information about the property, including its construction history, previous repairs, and any known issues. This will help you to identify potential problem areas and focus your inspection efforts accordingly.

External Inspection

Roof

Begin your inspection by examining the roof. Look for any signs of damage to the concrete tiles, such as cracks or missing tiles. Check the condition of the timber rafters and purlins, ensuring that they are free from rot and other forms of deterioration.

External Walls

Next, inspect the external walls for signs of spalling or other damage to the clinker PC blocks. Pay particular attention to areas where moisture may have penetrated the surface, as this can indicate underlying issues with the wall structure.

Internal Inspection

Ground Floor

Inspect the ground floor for any signs of damage to the concrete slab. Look for cracks or uneven surfaces, which may indicate subsidence or other structural issues. Check the condition of the DPC (damp-proof course) to ensure that it is intact and functioning correctly.

First Floor

Examine the first floor for any signs of damage to the timber joists and tongue-and-groove boarding. Look for signs of rot or insect infestation, which can weaken the floor structure and pose a safety risk.

PRC Columns

Inspect the PRC columns for signs of corrosion or other damage. Pay particular attention to areas where the cover to reinforcement may be inadequate, as this can increase the risk of structural failure.

Additional Considerations

Separating Walls

Check the condition of the separating walls, ensuring that they provide adequate sound insulation between adjoining properties. Look for any signs of damage or deterioration, which may indicate underlying issues with the wall structure.

Ceilings

Inspect the ceilings for any signs of damage or sagging. Look for cracks or other signs of structural issues, which may indicate problems with the roof or upper floor structure.

Typical Construction Details

Substructure

The substructure of Gregory Houses typically consists of concrete strip footings and an 11″ filled brick cavity underbuilding. A damp-proof course (DPC) is installed to prevent moisture from rising through the walls, and a concrete slab forms the ground floor.

Frame

The frame of a Gregory House is constructed from storey-height PC columns, mortared into rebates in PC plinth units. These columns are reinforced with steel and provide the primary structural support for the building. PRC corner columns and intermediate columns are also used to enhance the structural integrity of the frame.

External Walls

The external walls are made from reconstituted Ketton stone-faced clinker PC blocks, with a 2″ cavity and 3″ x 9 3/4″ PC blocks to the first-floor level. Lightweight concrete block walls are located axially on the columns, and timber buttresses are tied to the block walls with twisted metal lugs above.

Separating Wall

The separating wall between adjoining properties is constructed from an 11″ lightweight PC block cavity wall, providing adequate sound insulation and structural support.

Ground Floor

The ground floor is made from concrete, providing a durable and stable base for the property.

First Floor

The first floor consists of tongue-and-groove boarding on timber joists, providing a solid and stable surface for the upper level of the property.

Roof

The roof is constructed from timber rafters and purlins, covered with concrete tiles. This design provides a durable and weather-resistant roof structure, while also offering additional living space in the attic.

Typical Defects in Gregory Houses

Spalling of External Wall Clinker PC Blocks

As previously mentioned, spalling of external wall clinker PC blocks is a common issue with Gregory Houses. This occurs when moisture penetrates the surface of the blocks, causing them to crack and flake. Over time, this can compromise the structural integrity of the walls and lead to costly repairs.

Inadequate Cover to Reinforcement in PRC Columns

Inadequate cover to reinforcement in PRC columns is another significant defect associated with Gregory Houses. This can result in the corrosion of the steel reinforcement, weakening the columns and potentially leading to structural failure.

Medium Chloride Level in PRC Columns

The presence of medium chloride levels in PRC columns is also a concern. Chlorides can accelerate the corrosion of steel reinforcement, further exacerbating the risk of structural damage.

Roof Issues

The roof of a Gregory House can also be prone to issues such as cracked or missing concrete tiles, rot in the timber rafters and purlins, and leaks. Regular maintenance and timely repairs are essential to prevent these issues from escalating.

Ground Floor Issues

The ground floor of a Gregory House can be susceptible to issues such as cracks in the concrete slab, subsidence, and problems with the damp-proof course (DPC). These issues can compromise the structural integrity of the property and lead to costly repairs.

First Floor Issues

The first floor of a Gregory House can also be prone to issues such as rot or insect infestation in the timber joists and tongue-and-groove boarding. These issues can weaken the floor structure and pose a safety risk.

Conclusion

The Gregory House is a unique and historically significant property type in the UK, with distinctive construction characteristics and potential hazards that home buyers and investors need to be aware of. By understanding the typical features, risks, and defects associated with these properties, you can make informed decisions and take the necessary steps to safeguard your investment.
