Historical Context and Background

The MOW Demonstration No-Fines house, also known as the No-Fines house, is a unique property type that emerged in the 1940s. Designed by the Ministry of Works (MOW), this property was part of a post-war initiative to address the housing shortage in the UK. Only two of these houses were built, making them rare and intriguing for both home buyers and property investors.

The term “No-Fines” refers to the type of concrete used in the construction of these houses. Unlike traditional concrete, which includes fine aggregates like sand, No-Fines concrete is made using only coarse aggregates and cement. This results in a lighter, more porous material that offers several advantages, including better thermal insulation and reduced material costs.

Typical Locations and Manufacturers

Given their limited production, MOW Demonstration No-Fines houses are not widespread. They are typically found in areas where the Ministry of Works had significant influence during the 1940s. These houses were part of a broader effort to experiment with different construction techniques to quickly and efficiently provide housing for the growing population.

The Ministry of Works was the primary designer and manufacturer of these houses. Their involvement ensured that the properties adhered to specific standards and guidelines, making them a reliable option for those looking to invest in unique, historically significant homes.

Characteristics and Features

External Features

MOW Demonstration No-Fines houses are easily identifiable by their distinct architectural features. These two-storey semi-detached houses have a steep pitch gable roof covered with tiles. The external walls are rendered throughout, giving them a uniform and aesthetically pleasing appearance. A flat canopy over the front door adds a touch of character to these otherwise utilitarian structures.

Internal Features

Internally, these houses are designed for practicality and durability. The ground floor typically features concrete flooring, while the first floor consists of timber boarding on timber joists. The ceilings’ construction details are not well-documented, but they are likely to be consistent with other properties from the same era.

Structural Elements

The main structural elements of MOW Demonstration No-Fines houses include:

• Substructure: Concrete strip footings and dense concrete underbuilding provide a solid foundation. A concrete slab and damp-proof course (DPC) are also integral parts of the substructure.
• External Walls: The external walls are rendered and made from 12-inch clinker aggregate No-Fines concrete. They include 3/8-inch continuous bar reinforcement surrounded by cement mortar, providing additional strength and stability.
• Separating Wall: An 8-inch ballast aggregate No-Fines concrete wall separates the two semi-detached units.
• Partitions: Internal partitions are made from 4-inch ballast aggregate No-Fines concrete.
• Roof: The roof structure consists of timber rafters, purlins, and tiles.

Hazards and Risks

Structural Integrity

One of the primary concerns with MOW Demonstration No-Fines houses is the potential for structural issues. The use of No-Fines concrete, while innovative, can lead to problems if not properly maintained. Over time, the porous nature of the material can allow moisture to penetrate, leading to corrosion of the steel reinforcement bars. This can compromise the structural integrity of the property.

Thermal Insulation

While No-Fines concrete offers better thermal insulation compared to traditional concrete, it is still not as effective as modern insulation materials. Homeowners may need to invest in additional insulation to meet current energy efficiency standards.

Damp and Moisture

The porous nature of No-Fines concrete can also lead to issues with damp and moisture. Proper maintenance of the damp-proof course (DPC) is essential to prevent moisture from rising through the concrete slab and causing damage to the internal structure.

Defective Premises Act

MOW Demonstration No-Fines houses are not classified as defective under the Defective Premises Act. However, potential buyers should be aware of the unique construction methods and materials used in these properties. A thorough survey is recommended to identify any potential issues and ensure the property is in good condition.

Inspection and Assessment

Tools and Equipment

When inspecting a MOW Demonstration No-Fines house, surveyors should be equipped with the following tools:

• Moisture meter: To detect damp and moisture levels in the walls and floors.
• Thermal imaging camera: To assess the effectiveness of the insulation and identify any thermal bridges.
• Endoscope: To inspect the condition of the steel reinforcement bars within the No-Fines concrete.
• Concrete cover meter: To measure the depth of the concrete cover over the reinforcement bars.

Inspection Process

1. External Inspection: Begin by examining the external walls for signs of cracking, spalling, or other damage. Pay particular attention to areas around windows and doors, as these are common points of entry for moisture.

2. Roof Inspection: Inspect the roof for any missing or damaged tiles. Check the condition of the timber rafters and purlins, and look for signs of rot or insect infestation.

3. Internal Inspection: Inside the property, use a moisture meter to check for damp in the walls and floors. Inspect the condition of the timber joists and boarding on the first floor. Look for any signs of structural movement, such as cracks in the walls or ceilings.

4. Reinforcement Inspection: Use an endoscope and concrete cover meter to assess the condition of the steel reinforcement bars within the No-Fines concrete. Look for signs of corrosion, which can compromise the structural integrity of the property.

5. Thermal Imaging: Use a thermal imaging camera to assess the effectiveness of the insulation. Identify any areas where heat is escaping, and recommend additional insulation if necessary.

Typical Defects and Maintenance

Common Defects

1. Cracking and Spalling: Over time, the No-Fines concrete can develop cracks and spalling, particularly in areas exposed to moisture. Regular inspections and prompt repairs are essential to prevent further damage.

2. Corrosion of Reinforcement Bars: The porous nature of No-Fines concrete can allow moisture to reach the steel reinforcement bars, leading to corrosion. This can weaken the structure and require costly repairs.

3. Damp and Moisture: Proper maintenance of the damp-proof course (DPC) is essential to prevent moisture from rising through the concrete slab. Regular inspections and repairs can help mitigate this issue.

4. Thermal Insulation: While No-Fines concrete offers better thermal insulation than traditional concrete, it may not meet current energy efficiency standards. Additional insulation may be required to improve the property’s thermal performance.

Maintenance Tips

1. Regular Inspections: Conduct regular inspections of the property to identify and address any issues early. This can help prevent minor problems from becoming major repairs.

2. Moisture Control: Ensure that the damp-proof course (DPC) is in good condition and functioning properly. Address any issues with damp and moisture promptly to prevent damage to the structure.

3. Reinforcement Protection: Protect the steel reinforcement bars from corrosion by maintaining the concrete cover and addressing any cracks or spalling promptly.

4. Insulation Upgrades: Consider upgrading the insulation to improve the property’s energy efficiency. This can help reduce heating costs and improve the overall comfort of the home.

Conclusion

The MOW Demonstration No-Fines house is a unique and historically significant property type that offers several advantages and challenges for home buyers and investors. Understanding the construction methods, potential hazards, and maintenance requirements is essential for making an informed decision.
