Overview of the Russell-Leighton House

The Russell-Leighton house, a distinctive property type from the 1940s, stands as a testament to the innovative construction methods of its time. Designed and manufactured by Russell-Leighton (Contractors) Ltd, these properties are primarily found in the UK and are known for their unique construction characteristics. This article delves into the various aspects of the Russell-Leighton house, providing a detailed guide for home buyers and investors.

Historical Context and Manufacturing

Period Built

The Russell-Leighton houses were constructed during the 1940s, a period marked by a significant demand for housing due to the aftermath of World War II. The need for rapid and cost-effective construction methods led to the development of system-built properties like the Russell-Leighton house.

Manufacturers and Designers

Russell-Leighton (Contractors) Ltd were both the manufacturers and designers of these properties. Their innovative approach to construction involved the use of pre-cast reinforced concrete (PRC) components, which allowed for quicker assembly and reduced labour costs.

Number Built

While the exact number of Russell-Leighton houses built is not well-documented, it is known that these properties were part of a broader effort to address the housing shortage in the UK during the 1940s. They are typically found in suburban areas, often as part of larger housing estates.

Identification Characteristics

General Appearance

Russell-Leighton houses are typically two-storey semi-detached properties. They feature a medium pitch gable roof covered with plain concrete tiles, which is a distinctive characteristic. The external walls are composed of exposed storey-height pre-cast (PC) columns and PC panels, giving the houses a unique and recognisable appearance.

Key Features

• PC String Course Units: These are located at the first-floor level and add to the structural integrity and aesthetic appeal of the house.
• Flat Canopy Over Front Door: This feature provides a practical and visual element to the entrance of the house.

Construction Details

Substructure

The substructure of Russell-Leighton houses consists of concrete strip foundations and brick under-building. A damp-proof membrane (DPM) is also included to prevent moisture ingress.

External Walls

The external walls are constructed using foamed slag aggregate reinforced concrete (RC) base units and gusset blocks. The walls also feature foamed slag aggregate rebated PRC columns and PC panels, which are greater than 12 inches by less than 3 feet by 2 inches. The walls include cavities and insulation to enhance thermal performance.

Separating Wall

The separating wall between semi-detached units is a 3-inch foamed slag aggregate column and PRC foamed slag aggregate PC panel cavity wall. This construction method provides both structural support and sound insulation.

Partitions

Internal partitions are made of 2-inch foamed slag aggregate PC panels and PRC foamed slag aggregate columns. In some variants, partitions may be constructed using 3-inch clinker concrete.

Ground Floor

The ground floor consists of timber boarding on timber battens, which are infilled with concrete. This construction method provides a solid and durable base for the ground floor.

First Floor

The first floor features timber boarding on timber joists, which are bolted to rolled steel angles (RSA). This provides a robust and stable structure for the upper floor.

Roof

The roof is constructed using RC roof trusses, purlins, and PRC eaves units, and is covered with concrete tiles. This combination of materials ensures a strong and weather-resistant roof structure.

Typical Hazards and Risks

Structural Issues

One of the primary concerns with Russell-Leighton houses is the potential for structural issues related to the use of PRC components. Over time, these components can deteriorate, leading to problems such as cracking and spalling of concrete, and corrosion of the steel reinforcement.

Moisture Ingress

Due to the age of these properties, moisture ingress can be a significant issue. The damp-proof membrane (DPM) may have deteriorated, leading to rising damp and associated problems such as mould and mildew.

Insulation and Energy Efficiency

The original insulation in Russell-Leighton houses may no longer meet modern standards. This can result in poor energy efficiency and higher heating costs. Upgrading the insulation can be a necessary and beneficial improvement.

Defective Premises Act

Classification as Defective

Russell-Leighton houses are not specifically classified as defective under the Defective Premises Act. However, due to the potential issues with PRC components, they may be considered defective if significant structural problems are identified. It is essential for buyers and investors to conduct thorough surveys and assessments to determine the condition of the property.

Inspection and Assessment Guide

Pre-Inspection Preparation

Before conducting an inspection, it is crucial to gather as much information as possible about the property. This includes reviewing any available documentation, such as previous survey reports, maintenance records, and building plans.

External Inspection

• Roof: Check for any signs of damage or deterioration in the concrete tiles and RC roof trusses. Look for missing or broken tiles and inspect the condition of the purlins and eaves units.
• Walls: Examine the external walls for cracks, spalling, and signs of moisture ingress. Pay particular attention to the PC columns and panels, as these are prone to deterioration.
• Canopy and String Course Units: Inspect the flat canopy over the front door and the PC string course units at the first-floor level for any signs of damage or wear.

Internal Inspection

• Ground Floor: Check the condition of the timber boarding and timber battens. Look for any signs of moisture ingress or deterioration in the concrete infill.
• First Floor: Inspect the timber joists and boarding for any signs of damage or instability. Ensure that the joists are securely bolted to the RSA.
• Partitions and Separating Walls: Examine the internal partitions and separating walls for any signs of cracking or movement. Check for any issues with the foamed slag aggregate columns and PC panels.

Moisture and Insulation

• Damp-Proof Membrane: Assess the condition of the DPM and look for any signs of rising damp. Use a moisture meter to check for elevated moisture levels in the walls and floors.
• Insulation: Evaluate the existing insulation and determine if it meets current standards. Consider upgrading the insulation to improve energy efficiency and reduce heating costs.

Typical Defects and Maintenance

Common Defects

• Cracking and Spalling: Cracks in the concrete components and spalling of the concrete surface are common issues. These defects can compromise the structural integrity of the property and should be addressed promptly.
• Corrosion of Steel Reinforcement: The steel reinforcement within the PRC components can corrode over time, leading to further deterioration of the concrete. Regular inspections and maintenance are essential to identify and address this issue.
• Moisture Ingress: As mentioned earlier, moisture ingress can be a significant problem in Russell-Leighton houses. Addressing issues with the DPM and ensuring proper drainage around the property can help mitigate this risk.

Maintenance Tips

• Regular Inspections: Conduct regular inspections of the property to identify and address any issues early. This includes checking the condition of the roof, walls, and internal components.
• Concrete Repairs: If cracks or spalling are identified, carry out concrete repairs promptly to prevent further deterioration. This may involve patching, sealing, or even replacing damaged components.
• Moisture Control: Ensure that the DPM is in good condition and that proper drainage is maintained around the property. Address any signs of rising damp or moisture ingress promptly to prevent further damage.

Conclusion

The Russell-Leighton house is a unique and historically significant property type that offers both opportunities and challenges for home buyers and investors. Understanding the construction details, typical hazards, and maintenance requirements is essential for making informed decisions about these properties. By conducting thorough inspections and addressing any issues promptly, buyers and investors can ensure the long-term durability and value of their Russell-Leighton house.
