Overview of Thornwall Houses

The Thornwall house, a product of Thornwall Construction Ltd, is a notable example of system-built properties from the 1960s. These homes, also known as Thornwall 3M or Thornwood, were primarily constructed as bungalows and two-storey terraced houses. With a total of 260 units built, these properties are scattered across various locations in the UK, often found in suburban areas.

Historical Context and Manufacturers

Thornwall Construction Ltd

Thornwall Construction Ltd was a prominent player in the post-war housing boom, focusing on creating affordable and quickly constructed homes to address the housing shortage. The company’s innovative approach to using prefabricated reinforced concrete (PRC) panels allowed for rapid assembly and cost-effective production.

Design and Construction Period

The Thornwall houses were designed and built during the 1960s, a period marked by a significant demand for new housing. The design aimed to provide functional and durable homes that could be constructed swiftly to meet the growing needs of the population.

Typical Characteristics of Thornwall Houses

Architectural Features

Thornwall houses are easily identifiable by their medium pitch gable roofs covered with interlocking concrete tiles or flat roofs with bituminous felt. The external walls are made of storey-height exposed aggregate PRC panels, giving them a distinctive appearance. Some variations include gable apexes of timber boarding, adding a unique touch to the design.

Internal Layout

The internal layout of Thornwall houses typically includes timber stud partitions lined with plasterboard, timber boarding on timber joists for the ground floor, and plasterboard ceilings. The first floor construction details are less documented but are generally consistent with the robust and practical design ethos of the period.

Typical Hazards and Risks

Structural Concerns

One of the primary concerns with Thornwall houses is the potential for structural issues related to the PRC panels. Over time, these panels can suffer from corrosion of the steel reinforcement, leading to cracking and spalling of the concrete. This can compromise the structural integrity of the building if not addressed promptly.

Moisture Ingress

The flat roofs covered with bituminous felt are particularly susceptible to moisture ingress, which can lead to dampness and mould issues within the property. Regular maintenance and timely repairs are essential to prevent these problems from escalating.

Insulation and Energy Efficiency

The original construction of Thornwall houses included 1/2″ polystyrene insulation, which is significantly below modern standards. As a result, these homes may have poor energy efficiency, leading to higher heating costs and potential discomfort for occupants.

Defective Premises Act and Thornwall Houses

Classification as Defective

Thornwall houses are not specifically listed as defective under the Defective Premises Act. However, the potential issues with PRC panels and other construction elements mean that they require careful inspection and maintenance to ensure they remain safe and habitable.

Inspection Guide for Surveyors

External Inspection

1. Roof: Check for signs of wear and tear on the interlocking concrete tiles or bituminous felt. Look for any evidence of leaks or water damage.
2. Walls: Inspect the exposed aggregate PRC panels for cracks, spalling, or other signs of deterioration. Pay particular attention to the condition of the steel reinforcement within the panels.
3. Gable Apex: If present, examine the timber boarding for signs of rot or insect infestation.

Internal Inspection

1. Partitions: Assess the condition of the timber stud partitions and plasterboard linings. Look for any signs of dampness or structural movement.
2. Floors: Check the timber boarding and joists for signs of rot, insect damage, or structural weakness.
3. Ceilings: Inspect the plasterboard ceilings for cracks, sagging, or other signs of damage.

Substructure

1. Footings: Examine the concrete strip footings and brick under-building for signs of settlement or movement.
2. DPC: Ensure the damp-proof course (DPC) is intact and functioning correctly to prevent rising damp.

Typical Construction Details

Roof

The roofs of Thornwall houses are constructed using braced and strutted timber and steel units, covered with interlocking concrete tiles or bituminous felt. The design provides a robust and durable roofing solution, although regular maintenance is essential to address any potential issues.

Walls

The external walls are made of storey-height exposed aggregate PRC panels, with a weather bar and vertical bituminous damp-proof membrane (DPM) for added protection. The walls also include 1/2″ polystyrene insulation and honeycomb plasterboard, providing a basic level of thermal insulation.

Floors

The ground floor consists of timber boarding on timber joists, while the first floor construction details are less well-documented. The use of timber provides a lightweight and flexible flooring solution, although it requires regular inspection and maintenance to ensure its longevity.

Main Frame

The main frame of Thornwall houses includes PRC columns and load-bearing partitions of precast concrete panels. The use of these materials provides a strong and durable structural framework, although the potential for corrosion of the steel reinforcement within the PRC panels is a key concern.

Typical Defects in Thornwall Houses

Corrosion of Steel Reinforcement

One of the most common defects in Thornwall houses is the corrosion of the steel reinforcement within the PRC panels. This can lead to cracking and spalling of the concrete, compromising the structural integrity of the building. Regular inspection and timely repairs are essential to address this issue.

Moisture Ingress and Dampness

The flat roofs covered with bituminous felt are particularly prone to moisture ingress, leading to dampness and mould issues within the property. Regular maintenance and timely repairs are essential to prevent these problems from escalating.

Poor Insulation and Energy Efficiency

The original construction of Thornwall houses included 1/2″ polystyrene insulation, which is significantly below modern standards. As a result, these homes may have poor energy efficiency, leading to higher heating costs and potential discomfort for occupants.

Maintenance and Repair Recommendations

Addressing Structural Issues

To address structural issues related to the PRC panels, it is essential to regularly inspect the condition of the steel reinforcement and concrete. If corrosion is detected, appropriate repairs should be carried out promptly to prevent further deterioration.

Improving Insulation

To improve the energy efficiency of Thornwall houses, consider upgrading the insulation in the walls, roof, and floors. This can help to reduce heating costs and improve the overall comfort of the property.

Roof Maintenance

Regular maintenance of the roof is essential to prevent moisture ingress and associated issues. This includes inspecting the condition of the interlocking concrete tiles or bituminous felt and carrying out any necessary repairs.

Conclusion

Thornwall houses, with their distinctive design and construction, offer a unique opportunity for home buyers and investors. However, it is essential to be aware of the potential issues related to the PRC panels, moisture ingress, and insulation. Regular inspection and maintenance are key to ensuring these properties remain safe and habitable.
