Understanding the Fredericks Frame System House

The Fredericks Frame System house, a unique architectural marvel from the 1960s, stands as a testament to the innovative spirit of its era. Designed by Maurice R Day & Associates and manufactured by Fredericks & Pelhams Timber Buildings Ltd, these homes were part of a limited production run, with only 50 units ever built. Known alternatively as Fredericks Industrialised Timber or simply Fredericks, these properties are primarily found in the UK, offering a distinctive blend of design and functionality.

Historical Context and Manufacturing Details

The 1960s was a period marked by rapid industrialisation and a growing demand for affordable housing solutions. The Fredericks Frame System emerged as a response to this demand, leveraging the industrialised timber construction techniques that were gaining popularity at the time. Fredericks & Pelhams Timber Buildings Ltd, the manufacturer, was at the forefront of this movement, producing homes that were both cost-effective and quick to assemble.

These homes were primarily constructed as bungalows and two-storey terraced houses, featuring a shallow pitch gable roof covered with concrete tiles or a flat roof with bituminous felt. The design was characterised by its use of horizontal timber boarding or timber frame panels, with asbestos cement sheets below the windows on the first floor and either horizontal timber boarding or tile hanging above. The gable or flank walls were typically constructed of brick, adding a touch of traditional masonry to the otherwise modern design.

Key Characteristics and Identification

Identifying a Fredericks Frame System house involves recognising several distinct features. These homes often include a single-storey felted flat roof semi-integral garage attached to the front external wall. The front and rear external walls are clad with horizontal timber boarding, while the gable walls are clad with brick. The use of asbestos cement sheets below the windows is another hallmark of this design, although some variants feature tile hanging on timber battens for the upper storey.

The construction of these homes is based on a platform frame system, with storey-height timber frame panels sheathed externally with plywood and overlaid with breather paper. This is directly clad with horizontal timber boarding, while the gable wall is separately clad with brick. The internal lining consists of foil-backed plasterboard, with mineral fibre insulation between the frame studs. The separating walls are timber frame cavities lined with two layers of plasterboard and asbestos cement sheets in the roof space, providing additional insulation and fire resistance.

Construction Details

The substructure of a Fredericks Frame System house is built on concrete strip footings, with concrete under-building and slab. A damp-proof course (DPC) is included to prevent moisture ingress. The ground floor is typically concrete, while the first floor consists of plywood on timber joists. Ceilings are made of plasterboard, with foil-backed plasterboard used in the roof space for added insulation.

The roof is constructed using timber trusses, covered with bituminous felt and concrete tiles. Mineral fibre insulation is installed at ceiling level to enhance thermal efficiency. Some variants of these homes feature ground floor front and rear external walls directly clad with asbestos cement sheets below the windows, while the upper storey is separately clad with tile hanging on timber battens.

Potential Hazards and Risks

While the Fredericks Frame System house offers a unique architectural style, it is not without its potential hazards and risks. One of the primary concerns is the use of asbestos cement sheets, which were commonly used in construction during the 1960s. Asbestos is a known health hazard, and any disturbance of these materials can release harmful fibres into the air. It is crucial to have a professional surveyor assess the presence and condition of asbestos in these homes before any renovation or demolition work is undertaken.

Another potential risk is the timber frame construction itself. While timber is a durable and sustainable building material, it is susceptible to rot and insect infestation if not properly maintained. Regular inspections and maintenance are essential to ensure the longevity and structural integrity of these homes.

Defective Premises Act Considerations

The Defective Premises Act, enacted in 1972, aims to protect homeowners from defects in the construction of their properties. While the Fredericks Frame System house predates this legislation, it is still important to consider the potential for defects when purchasing or investing in one of these homes. Common defects in timber-framed houses include issues with the structural frame, insulation, and cladding materials. A thorough inspection by a qualified surveyor can help identify any existing or potential defects and provide guidance on necessary repairs or improvements.

Inspection Tips for Fredericks Frame System Houses

When inspecting a Fredericks Frame System house, there are several key areas to focus on:

1. Roof and Ceiling: Check for signs of water damage or leaks, particularly around the roof trusses and ceiling insulation. Inspect the condition of the bituminous felt and concrete tiles, and ensure that the roof is properly ventilated to prevent moisture buildup.

2. External Walls: Examine the condition of the horizontal timber boarding and brick cladding. Look for signs of rot, insect infestation, or damage to the breather paper and plywood sheathing. Pay special attention to the asbestos cement sheets, and consider having them tested for asbestos content.

3. Internal Walls and Partitions: Inspect the plasterboard lining for cracks or damage, and check the condition of the mineral fibre insulation between the frame studs. Ensure that the separating walls provide adequate sound and fire insulation.

4. Floors: Assess the condition of the concrete ground floor and the plywood on timber joists for the first floor. Look for signs of moisture ingress or structural movement.

5. Substructure: Examine the concrete strip footings and under-building for signs of settlement or cracking. Ensure that the damp-proof course is intact and functioning effectively.

Common Defects and Maintenance Tips

Fredericks Frame System houses, like any other property, are susceptible to certain defects over time. Common issues include:

• Timber Rot and Insect Infestation: Regularly inspect and treat the timber frame and cladding to prevent rot and insect damage. Ensure that the property is well-ventilated and free from moisture buildup.

• Asbestos Concerns: If asbestos cement sheets are present, have them assessed by a professional and consider removal or encapsulation if necessary. Avoid disturbing these materials during renovations.

• Insulation and Energy Efficiency: Check the condition of the mineral fibre insulation and consider upgrading to modern, more efficient materials if needed. Ensure that the property is well-insulated to reduce energy costs and improve comfort.

• Structural Movement: Monitor the property for signs of structural movement, such as cracks in the walls or floors. Address any issues promptly to prevent further damage.

Conclusion

The Fredericks Frame System house is a unique and historically significant property type that offers both charm and challenges. Understanding the construction details, potential hazards, and common defects associated with these homes is essential for prospective buyers and investors. By conducting a thorough inspection and addressing any issues promptly, you can ensure the longevity and safety of your investment.
